Harvesting

AS-H320 Disc Mower Conditioner

Low-profile disc bed with steel-tine conditioning cracks stems for a faster, even wilt.

  • Dimensions4,150 × 1,850 × 1,350 mm (work position)
  • Working Width3.2 m
  • Power RequirementTractor 90–120 hp class, 540 rpm PTO
  • CapacitySwath width adjustable 1.2–2.2 m

Response within one business day. Include duty point or application details for a faster match.

Technical Specifications

Dimensions 4,150 × 1,850 × 1,350 mm (work position)
Working Width 3.2 m
Power Requirement Tractor 90–120 hp class, 540 rpm PTO
Capacity Swath width adjustable 1.2–2.2 m
Weight 1,340 kg
Certification CE machinery directive design basis
Warranty 24 months

Overview

The AS-H320 cuts forage with a low-profile disc bed and passes the crop straight through a steel-tine conditioner, cracking the waxy stem surface so the swath wilts evenly. The result is forage that reaches baling or ensiling moisture sooner, with less field time and weather risk.

The cutter bar is modular: each disc runs on its own repairable module, and a shear-protection hub keeps an impact from travelling down the drive train. Conditioning intensity adjusts on a single lever, and the machine swings behind the tractor for transport inside legal width.
