The distribution-center workhorse: quiet 24 V driven rollers with zone-based accumulation.
Response within one business day. Include duty point or application details for a faster match.
| Throughput | up to 3,600 cases/h |
|---|---|
| Usable width | 420 / 620 / 840 mm |
| Speed range | 0.1 to 1.2 m/s |
| Load capacity | 50 kg per zone |
| Frame | Powder-coated steel, bolted |
| Power | 24 V DC zoned drives |
| Warranty | 2 years |
The CVR-P moves cartons and totes on motorized rollers grouped into independent zones, so product accumulates without touching and restarts without a jolt. Zones sleep when empty, which keeps noise and energy draw low on long lines.
Frames arrive pre-assembled in plug-and-play sections with connectors fitted. Straight sections, curves and transfers share the same roller cartridge, so one spare covers the whole line.
Zero-power flow for pick lines and loading bays, with tapered rollers that hold the…
