Case-hardened helical teeth, ground after heat treat, sharing one housing with the motor.
Response within one business day. Include duty point or application details for a faster match.
| Power range | 0.37 to 75 kW |
|---|---|
| Speed | output 0.1 to 500 rpm |
| Torque | up to 12 000 Nm |
| Ratio | 3:1 to 12 000:1 staged |
| Mounting | Foot, flange or shaft |
| Protection | IP55 gear unit |
| Warranty | 2 years |
The TD-G310 combines a motor and two- or three-stage helical reducer in one rigid housing, eliminating couplings, guards and alignment shims. Ground helical gearing keeps noise low and efficiency high through the whole ratio range.
Housings are ribbed cast iron with oversized output bearings for belt and chain loads. Supplied filled with long-life synthetic oil, mounted in any orientation you specify at order.
Bronze worm wheel on a hardened steel screw; the tall ratios hold load without…
