Interior magnets hold IE4 efficiency two frame sizes below the induction motor it replaces.
Response within one business day. Include duty point or application details for a faster match.
| Power range | 1.5 to 160 kW |
|---|---|
| Speed | 500 to 4500 rpm |
| Torque | up to 900 Nm |
| Efficiency class | IE4 design |
| Frame size | 90 to 280 |
| Protection | IP54 or IP65 |
| Warranty | 3 years |
The TD-P210 replaces induction motors where energy cost or cabinet space rules the decision. Permanent-magnet rotors cut rotor losses to nearly zero, holding full-load efficiency across a wide speed band — exactly where fans, pumps and extruders spend their lives.
The smooth aluminium housing sheds heat without deep fins, so wash-down and hygiene-sensitive installations stay easy to clean. Pairs with our TD-V series drives out of the box.
A cast-in water-glycol jacket replaces the fan, so rated torque holds down to standstill.
View & InquireTell us about your application and required quantity. Our engineers reply within one business day.
