Baking Ovens

CX-BO280 Rotary Rack Oven

Rotary rack oven that bakes every tray on the trolley to the same colour.

  • Dimensions1,720 × 1,580 × 2,450 mm
  • Throughput RangeOne 15–18 tray rack per cycle (typical)
  • Power Supply400 V three-phase; electric, gas or oil burner
  • Contact MaterialsAISI 304 stainless steel chamber

Response within one business day. Include duty point or application details for a faster match.

Technical Specifications

Dimensions 1,720 × 1,580 × 2,450 mm
Throughput Range One 15–18 tray rack per cycle (typical)
Power Supply 400 V three-phase; electric, gas or oil burner
Contact Materials AISI 304 stainless steel chamber
Cleaning Method Washdown chamber; removable door gasket
Certification CE machinery directive design basis
Warranty 24 months

Overview

The CX-BO280 rotates a full rack trolley inside a sealed baking chamber while heated air circulates in a controlled loop, so the top tray and the bottom tray leave with the same crust colour. Steam injection is metered per program for crusty breads and glossy pastries alike.

The chamber is welded stainless with coved corners, and the door seals on a replaceable food-grade gasket. Baking programs hold temperature, time, steam and fan profile; the panel runs them with a single start action, keeping results consistent across operators.

Rack handling uses a hook-and-rotate mechanism that accepts common trolley formats, and the hood recovers heat from exhaust air to the incoming supply, trimming energy use over long baking days.
