Joins two lanes into one clean stream with zoned control that never lets cartons collide.
Response within one business day. Include duty point or application details for a faster match.
| Throughput | up to 3,200 cases/h merged |
|---|---|
| Usable width | 620 mm both lanes |
| Speed range | 0.3 to 1.5 m/s |
| Load capacity | 50 kg per zone |
| Frame | Steel, 30-degree merge angle |
| Power | 24 V DC zoned drives |
| Warranty | 2 years |
The CVC-M brings a spur into the main line at a shallow angle, with zone sensors metering traffic so joining cartons slot into gaps instead of forcing them. Priority is configurable per lane — mains flow first, or strict alternation.
Guide rails and a powered transfer strip keep small cartons from wedging at the throat.
