Two independent lanes share one mast — up and down traffic in a single spiral footprint.
Response within one business day. Include duty point or application details for a faster match.
| Throughput | 2 x 1,200 units/h |
|---|---|
| Usable width | 2 lanes x 300 mm |
| Speed range | 0.3 to 0.8 m/s per lane |
| Load capacity | 35 kg/m per lane |
| Frame | Shared steel mast |
| Power | 2 x 2.2 kW |
| Warranty | 2 years |
When a mezzanine needs goods flowing both ways, the CVS-D stacks two independent spiral lanes on one central column. Each lane has its own drive and speed, so infeed and returns never compete for capacity.
The shared mast halves the floor space and structural steel of two separate spirals.
