Handling & Lifting

VG-VL0680 Vacuum Lifter

Mobile vacuum lifter that tilts and rotates sheets up to 680 kg.

  • Dimensions1,850 × 1,150 × 2,100 mm (mast folded)
  • Max Glass Size2,800 × 4,500 mm sheets
  • Glass Thickness RangeLoad capacity 680 kg
  • Power Supply48 V battery drive, on-board charger

Response within one business day. Include duty point or application details for a faster match.

Technical Specifications

Dimensions 1,850 × 1,150 × 2,100 mm (mast folded)
Max Glass Size 2,800 × 4,500 mm sheets
Glass Thickness Range Load capacity 680 kg
Power Supply 48 V battery drive, on-board charger
Processing Speed Full tilt-rotate cycle under 40 s (typical)
Certification CE machinery directive design basis
Warranty 24 months

Overview

The VG-VL0680 puts crane-class glass handling on wheels: a counterweighted mobile frame with a vacuum pad head that lifts, tilts through 90 degrees and rotates a sheet for placement. One operator moves what previously needed three, and the glass never takes an edge knock from a manual grip.

The vacuum system runs dual circuits with a reserve tank and audible low-vacuum warning, holding load safely through a power loss. Pad positions adjust on slotted arms for small units and odd shapes, and the mast folds for doorway transit between shop areas.
