Folding & Binding

PL-B450 Perfect Binder

Milling, notching, gluing and cover nipping in one clamp cycle. A caliper station sets book thickness itself.

  • Dimensions2,700 × 1,100 × 1,450 mm
  • Max Sheet SizeBook block up to 320 × 450 mm, spine to 50 mm
  • Rated SpeedUp to 350 cycles/hour (typical)
  • Registration AccuracyCover-to-block ±0.5 mm (typical)

Response within one business day. Include duty point or application details for a faster match.

Technical Specifications

Dimensions 2,700 × 1,100 × 1,450 mm
Max Sheet Size Book block up to 320 × 450 mm, spine to 50 mm
Rated Speed Up to 350 cycles/hour (typical)
Registration Accuracy Cover-to-block ±0.5 mm (typical)
Power Supply 400 V three-phase, 8 kW installed
Certification CE machinery directive design basis
Warranty 24 months

Overview

The PL-B450 binds softcover books, catalogues and manuals with hot-melt adhesive in a single-clamp cycle: milling, notching, gluing, cover nipping and delivery. It is sized for the short-run book work that digital presses feed — dozens to hundreds of copies, often of different titles in the same hour.

Book thickness sets automatically from a caliper station, and the cover scoring unit positions its creases from the same measurement, so a thickness change between titles does not send the operator around the machine with a wrench. Glue temperature and film thickness hold to setpoint through the shift.
