Ventilation

SP-V2000 Wall-Mounted Exhaust Hood

Two metres of grease-capturing canopy, welded seams, filters that drop into the dish machine.

  • Dimensions2000 × 1100 × 450 mm
  • PowerFan sized per project
  • Capacityapprox. 3000 m³/h extraction
  • MaterialAISI 430/304, welded seams

Response within one business day. Include duty point or application details for a faster match.

Technical Specifications

Dimensions 2000 × 1100 × 450 mm
Power Fan sized per project
Capacity approx. 3000 m³/h extraction
Material AISI 430/304, welded seams
Voltage 230 V lighting circuit
Certification Hygiene and fire-code ready
Warranty 5 years on fabrication

Overview

The SP-V2000 is a fully welded wall canopy sized for a two-metre cooking line. Internal baffles pull vapour through stainless grease filters at the velocity that actually captures it, and a full-perimeter gutter drains to a removable cup — grease never re-drips on the range.

Filters lift out and rack straight into the hood-type dish machine. The body is one welded assembly with sealed corners, and LED light channels come pre-wired. Matching duct collars and fire-damper prep are specified per project.

Request a Quote

Tell us about your application and required quantity. Our engineers reply within one business day.
