Basalt Electric Sauna Heater E90

A 9 kW floor-standing electric heater with a 60 kg stone bed, built for continuous commercial duty.

Model NS-E90
Dimensions 480 × 400 × 720 mm
Capacity Rooms 9 – 18 m³
Timber Not applicable
Heater Output 9.0 kW, 3 × 3 kW elements
Temperature Range 70 – 105 °C
Humidity Range 10 – 30 % RH with löyly
Power Supply 400 V / 3 ph / 16 A
Energy Use ≈ 6.4 kWh per session
Lead Time 3 weeks ex works
Send Full Specification
Description

Build detail and engineering notes

A heater is judged by what happens ninety seconds after water hits the stones. Thin stone beds give a sharp burst and then a cold room; the E90 carries 60 kg of split olivine diabase, enough thermal mass to absorb four or five ladles without the air temperature falling away.

Elements are Incoloy 800, staged in three banks so the controller can hold a set point rather than swinging around it.

Key Features

What is included as standard

60 kg stone bed Deep enough to hold heat through repeated löyly without collapsing temperature.
Stainless casing Brushed 304 stainless with a matte black powder finish.
Over-temperature cut-out Manual-reset thermal fuse independent of the controller.
Commercial duty rating Certified for twelve hours of continuous operation per day.
Product Inquiry

Basalt Electric Sauna Heater E90

Send us your room dimensions, ceiling height, intended capacity and power supply. Our technical team returns a specification, a layout drawing and a firm price — usually within two working days.
